Maten en specificaties
| Artikelnummer | d1 | l2 | l1 | d2 | sw |
|---|---|---|---|---|---|
| 512000640 | 6‚4-7‚2 mm | 32 mm | 111 mm | 3.8 mm | 3 mm |
| 512000720 | 7‚2-8 mm | 32 mm | 111 mm | 4.25 mm | 3.5 mm |
| 512000800 | 8-9 mm | 32 mm | 111 mm | 5.2 mm | 4.3 mm |
| 512000900 | 9-10 mm | 32 mm | 115 mm | 5.6 mm | 4.3 mm |
| 512001000 | 10-11 mm | 35 mm | 120 mm | 6.1 mm | 4.9 mm |
| 512001100 | 11-12 mm | 35 mm | 125 mm | 7.4 mm | 6.2 mm |
| 512001200 | 12-13‚5 mm | 42 mm | 130 mm | 8.4 mm | 6.2 mm |
| 512001350 | 13‚5-15‚5 mm | 50 mm | 145 mm | 9.4 mm | 7 mm |
| 512001550 | 15‚5-18 mm | 60 mm | 165 mm | 10.4 mm | 8 mm |
| 512001800 | 18-21 mm | 65 mm | 180 mm | 11.4 mm | 9 mm |
| 512002100 | 21-24 mm | 70 mm | 190 mm | 13.1 mm | 10 mm |
| 512002400 | 24-27‚5 mm | 75 mm | 205 mm | 14.1 mm | 11 mm |
| 512002750 | 27‚5-31‚5 mm | 80 mm | 225 mm | 16.1 mm | 12 mm |
| 512003150 | 31‚5-37 mm | 90 mm | 240 mm | 18.1 mm | 14.5 mm |
| 512003700 | 37-45 mm | 100 mm | 285 mm | 20.1 mm | 16 mm |
| 512004500 | 45-55 mm | 109 mm | 320 mm | 25.1 mm | 20 mm |
